ANSYS Workbench를 이용한 진동해석 > 기계공학

도서간략정보

ANSYS Workbench를 이용한 진동해석
신간도서
판매가격 15,000원
저자 심관보
도서종류 국내도서
출판사 도서출판 홍릉
발행언어 한국어
발행일 2024-06-28
페이지수 272
ISBN 9791156002093
배송비결제 주문시 결제
도서구매안내 온, 오프라인 서점에서 구매 하실 수 있습니다.

구매기능

  • 도서 정보

    도서 상세설명

    • [1] Vibration Concept
      1.1 Vibration analysis
      1.2 Understanding Vibration Basics
      1.3 Single degree of freedom system
      1.4 Spring Stiffness
      1.4.1 Calculate spring constant of one spring
      1.4.2 Equivalent spring constant k1+k2
      1.4.3 Equivalent spring constant k1 x k2
      1.4.4 Equivalent spring constant k1 x k2 + k3
      1.5 Beam analysis
      1.5.1 Cantilever Beam spring constant
      1.5.2 Fixed-Fixed Beam spring constant
      1.5.3 Spring structures on a cantilever
      1.5.4 Multiple spring structures attached to cantilever beam
      1.5.5 Natural frequency of the protruding beam

      [2] Damping system
      2.1 Definition of Damped System
      2.2 Examples of damped systems
      2.2.1 Displacement of cantilever with damping
      2.2.2 1 degrees-of-freedom damped vibration

      [3] Modal Analysis
      3.1 Overview of Modal Analysis
      3.2 Examples of Modal Analysis
      3.2.1 Lamel frame natural frequency
      3.2.2 Natural frequency of single-open explosion-proof door
      3.2.3 Natural frequency of each floor
      3.2.4 Cantilever natural frequency
      3.2.5 Hinge and fixed point column structure
      3.2.6 Hinge and hinge point column structure
      3.2.7 Slave with there column structure : Modal Analysis
      3.2.8 Slave with there column structure : Static Structure
      3.3. Multiple degrees of freedom system
      3.3.1 Degree-of-Freedom Vibration Characteristic

      [4] Harmonic Analysis
      4.1 Overview of Harmonic Analysis
      4.2 Transient Vibration
      4.2.1 Displacement of cantilever : Modal Analysis
      4.2.2 Displacement of cantilever : Static Structural
      4.2.3 Displacement of cantilever under Constant load
      4.2.4 Displacement of cantilever under Square load
      4.2.5 Displacement of cantilever under Sin load
      4.2.6 Displacement of cantilever under Tooth load
      4.2.7 Displacement of cantilecer under Blast Load
      4.3 Steady State Vibration : Harmonic Analysis
      4.3.1 Harmonic Response of Cantilever Beam
      4.3.2 Harmonic Response of Belt Pulley

      [5] Response Spectrum
      5.1 Response Spectrum Theory
      5.2 Apply Response Spectrum
      5.2.1 Two-story building spectrum analysis
      5.2.2 8-story building spectrum analysis
